CNC Lathe TCN-3500
- TCN-3500 / TCN-3500CM
- Realizing optimum rigidity balance in 10/12-inch class!
- Meet the various needs of customer.
Technical Specifications
Items | TCN-3500 L5 | TCN-3500 L10 |
---|---|---|
Chuck Size | 10in/12in | 10in/12in |
Bar Capacity | φ80mm (OP.φ108mm) | φ80mm (OP.φ108mm) |
Max. Turning Dia. | T8:φ430mm, T10:φ460mm, T12:φ460mm | T8:φ430mm, T10:φ460mm, T12:φ460mm |
Max. Turning Length | T8:485mm, T10:510mm, T12:510mm | T8:985mm, T10:1010mm, T12:1010mm |
Spindle Speed | 2500min-1(OP.3000min-1) | 2500min-1(OP.3000min-1) |
